Select Product
Voltage

Weighing Capacity

Readability

Balance Type

Pan Size

Model

Draft Shield

Draft Shield Type

Manufacturer SKU

Capacity Range

Terra Part # Price Ships in
120/240 V 120 g 0.1 mg Analytical 90 mm Secura Yes Micro SECURA124-1S 11 g - 200 g 5702-03 57629 $5,102 5-7 Days 2
Ships Free Free shipping in contiguous USA In stock
120/240 V 220 g 0.1 mg Analytical 90 mm Secura Yes Micro SECURA224-1S 201 g - 1000 g 5702-04 57630 $5,660 5-7 Days 3
Ships Free Free shipping in contiguous USA In stock
Voltage
Weighing Capacity
Readability
Balance Type
Pan Size
Model
Draft Shield
Draft Shield Type
Manufacturer SKU
Capacity Range
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • Secura Analytical Balances fulfill high reliability requirements for applications in regulated areas, such as pharmaceutical labs
  • Automatically monitors ambient conditions for better measurement results, prevents handling errors and increases reliability
  • Password protection prevents unauthorized changes
  • Designed for use in Laminar air flow environments with LevelControl and a pan draft shield (models 124 and 224 only)
  • LevelControl System—an optoelectronic sensor with alarm function ensures that balance is perfectly level
  • Automatic Calibration with isoCAL—user-determined, fully automatic temperature- and time-controlled internal adjustment to ensure consistently accurate results
  • Traceable sample identification for compliance with ISO, GLP, and GMP with the ability to define individual identifiers
  • Output can be blocked when questionable weighing results are detected due to incorrect calibration and leveling
  • Cal Audit Trail provides traceable documentation of all calibration and adjustment data inside the balance
  • Convenient built-in weighing applications developed for users in pharmaceutical laboratories
  • Includes universal power adapter, in-use dust cover, application guide, dust cover and draft ring for analytical balances, and draft shield/weighing chamber (dependent upon model)

Balances

  • Video of Sartorius Secura Analytical and Precision Balances demonstrating the different functions of the touchscreen Sartorius Secura Analytical and Precision Balances
Video of Sartorius Secura Analytical and Precision Balances demonstrating the different functions of the touchscreen
Features & Benefits

Features and Benefits

Learn More: Secura Balances

Secura Analytical and Precision Balances by Sartorius

Cal Audit Trail provides traceable documentation of all calibration and adjustment data

Secura features a Cal Audit Trail function to document the quality of each weigh-in procedure performed. Adjustment procedures including non-conformities recorded by the balance can be viewed on the touch screen, on a PC or printed.

Convenient built-in weighing applications developed for use in pharmaceutical laboratories

Secura balances are designed with built-in applications to make weighing more efficient by eliminating the need to fine-tune settings and reducing the possibility for weighing errors due to incorrect operation.

  • Check weighing: Determines whether packaged units are within a specific tolerance range and efficiently fills sample materials to a specified target weight
  • Components: Save up to 99 components weighed in various individual containers. Each container can be tared before each component is weighed.
  • Conversion: Multiplies or divides weight value by a user-defined factor (can be saved to protected memory)
  • Counting: Counts identical items (such as screws or tablets) easier, faster and more accurately compared to manual counting
  • Density Determination:   Determines the density of a solid object based on the buoyancy method (requires optional Specific Gravity Kit, sold separately)
  • Mixing: Automatically tares the balance after each component is weighed. The weight of an individual component or the total weight can be displayed
  • Peak Hold: Retains the peak value for display after weighing when a bulky sample covers the display or when a maximum force is quickly released
  • Percentage: Determines how much samples vary from a reference standard
  • Statistics: Saves weight and calculated values for up to 99 components and statistically analyzes them
  • Unstable Conditions: Secura balances provide accurate readings even under unstable environmental conditions, such as vibration or laminar flow, or when weighing moving laboratory animals
  • Weighing: Weighs various materials from chunks of solids to the finest quantities of pastes, powders, and liquids with incomparable weighing reliability
Intuitive Color touchscreen

The graphical, icon-driven interface feature applications developed for users in pharmaceutical laboratories. The screen functions even when operators are wearing gloves ideal for use in environments working with hazardous materials. Color-coded information and action fields reduce the chances for operating errors.

Data Management

The mini USB interface enables direct data output to Microsoft® Windows programs and data transfer protocols in SBI, xBPI, spreadsheet (table) or text formats. Data output can be automatically synchronized with the display, activated manually when a print command is received or at defined intervals. Output can be blocked when questionable weighing results are detected, such as when the balance is not level or is incorrectly calibrated. A computer connected via the data interface can send control commands to the balance to control its functions.

Designed for easy and thorough cleaning to prevent contamination

Secura lab balances have a streamlines design and rounded edges for easy and thorough cleaning to prevent contamination, protect work area safety and promote compliance with hygiene requirements. The sleek, innovative housing is acetone-cleanable. The practical and sturdy draft shield (on selected models) can be completely disassembled and is made of dishwasher-safe glass parts.

Specifications for Secura Balances
  • Selectable Weight Units: Gram, kilogram, carat, pound, ounce, troy ounce, Hong Kong tael, Singapore tael, Taiwan tael, grain, pennyweight, milligram, parts per pound, China tael, momme, Austrian carat, tola, baht, mesghal, Newton
  • Available Languages English: (default), Chinese, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish
  • Calibration: Automatic (isoCAL), internal, external
  • Leveling: Glass level indicator with air bubble for centering
  • Security: Compatible with Kensington lock-and-cable apparatus
  • Warranty: 2 years
  • Environment: For indoor use only
  • Ambient Temperature: +50° F to +86° F (+10°C to +30°C)
  • Operational Capacity: Guaranteed between 41°F to 113°F (+5°C and +45°C)
  • Storage and Shipping: 14°F to 140°F (-10°C to +60°C)
  • Relative Humidity: 15% to 80% for temperatures up to 87.8°F (31°C); non-condensing, decreasing linearly to 50% relative humidity at 104°F (40°C) and 20% at 122°F (50°C)
  • Elevation: Up to 3000 m above sea level
  • Safety of electrical equipment: In accordance with EN 61010-1/IEC 61010-1. Safety requirements for electrical equipment for measurement, control, and laboratory use – Part 1: General requirements.
  • Electromagnetic Compatibility: In accordance with EN 61326-1/IEC 61326-1. Electrical equipment for measurement, control, and laboratory use – EMC requirements – Part 1: General requirements.
  • Defined immunity to Interference: Suitable for use in industrial areas
  • Interference Emission: Class B (suitable for use in residential areas and areas that are connected to a low voltage network that also supplies residential buildings). The device can therefore be used in both areas.
  • Protection Ratings: Protection Class II, in accordance with EN | IEC 60950-1 up to 3000 m above sea level; IP40 as per EN | IEC 60529
  • Primary AC: Universal voltage, 100 to 240 V ±10%, 50 to 60 Hz, 0.2 A, typically 2 W
  • Secondary DC: 15 V ±5%, 530 mA (maximum), 8 W (maximum): 32°F to 104°F (0°C to +40°C), and 15 V ±5%, 330 mA (maximum), 5 W (maximum): 32°F to 122°F (0°C to +50°C)
  • Universal Power Adapters: Sartorius AC adaptor module 6971790 with interchangeable country-specific plug-in AC adaptors
  • CE-marked: Yes
Model Analytical Balances Prevision Balances
124 224 213 313 513 1102 2102 3102 5102
Weighing Capacity 120g 220g 210g 310g 510g 1100g 2100g 3100g 5100g
Weighing Pan Diameter 90 mm
(3.5 in.)
90 mm
(3.5 in.)
120 mm
(4.7 in.)
120 mm
(4.7 in.)
120 mm
(4.7 in.)
180 mm
(7 in.)
180 mm
(7 in.)
180 mm
(7 in.)
180 mm
(7 in.)
Readability 0.1 mg 0.1 mg 1 mg 1 mg 1 mg 10 mg 10 mg 10 mg 10 mg
Repeatability (standard deviation) 0.1 mg 0.1 mg 1 mg 1 mg 1 mg 10 mg 10 mg 10 mg 10 mg
Linearity Deviation 0.2 mg 0.2 mg 2 mg 2 mg 2 mg 20 mg 20 mg 20 mg 20 mg
Sensitivity drift between +10 and +30°C ±1.5 ppm/K ±1.5 ppm/K ±3 ppm/K ±3 ppm/K ±3 ppm/K ±3 ppm/K ±5 ppm/K ±3 ppm/K ±3 ppm/K
Typical Stabilization Time 2 s 2 s 1.5 s 1.5 s 1.5 s 1.5 s 1.5 s 1.5 s 1.5 s
Display result (depending on the set filter level) 0.2 s 0.2 s 0.1/02.s 0.1/02.s 0.1/02.s 0.1/02.s 0.1/02.s 0.1/02.s 0.1/02.s
isoCAL Settings
Temperature Change 1.5 K 1.5 K 4 K 4 K 2 K 4 K 4 K 4 K 2 K
Time Interval 4 h 4 h 12 h 12 h 6 h 24 h 12 h 12 h 6 h

Compliance with ISO, GLP and GMP

Interactive user guide for Secura balances defines identifiers, configures and print data with date and time stamps for traceable sample identification

isoCAL Automatic Calibration

Automatically adjusts uncalibrated Secura balances with internal weights and notifies the operator of incorrect results

Continuous Real-Time LevelControl System

Secura balances continuously monitor the level status and alerts the operator and halts data transfer in the event of detected tilts

Catalog of CE-Marked Products

Terra offers over 1,700 CE-marked products configured for international voltage requirements
Available Accessories
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Quintix Standard Thermal Line Laboratory Printer

    Printer automatically detects Sartorius balances when connected; includes USB cable, power cable, adapter and paper roll
