PRESTO A45 and A45t Air-Cooled Process System by Julabo for dynamic temperature control for components and material testing in automotive and space industries | 2440-PP-03 displayed
Circulators

PRESTO A45 Air-Cooled Process System, 5.5 kW, Julabo, 208-230V, 9420452.16

  • PRESTO A45 air-cooled processing system with a 5.5 kW heating capacity provides high-precision temperature control in automotive and aerospace components and materials testing
  • Cools water supply and quickly compensates exothermic and endothermic reactions
  • Long-life span ensured by exothermic and endothermic reactions
  • Various interfaces enable many remote control possibilities
  • Includes external Pt100 sensor connection (optional second Pt100 sensor), 5.7" industrial color TFT touchscreen

• Manufacturer SKU: 9420452.16

• Unit of Measure: EA

Read more
Stocked
Manufacturer SKU: 9420452.16
Manufactured By: Julabo
Warranty: One-Year Manufacturer Warranty (One-Year Additional Warranty with Product Registration)
Print
Need Help?

(714) 578-6100

Mon-Fri, 7am - 6pm PST

Chat

Want a quote quickly ?
Submit a QuickQuote request
Print
Need Help?

(714) 578-6100

Mon-Fri, 7am - 6pm PST

Chat

Want a quote quickly ?
Submit a QuickQuote request
2440-10
Terra Part # 2440-10
$52,415
Usually ships in 5-5 business days

Want it faster ? Read about FasTrak

In stock
Terra Part # 2440-10
82586
$52,415
Usually ships in 5-5 business days

Want it faster ? Read about FasTrak

In stock
Save For Later
Details & Specs
Manuals & Resources
Related Products
Product Details
  • PRESTO A45 air-cooled processing system with a 5.5 kW heating capacity provides high-precision temperature control in automotive and aerospace components and materials testing
  • Cools water supply and quickly compensates exothermic and endothermic reactions
  • Long-life span ensured by exothermic and endothermic reactions
  • Various interfaces enable many remote control possibilities
  • •  Includes external Pt100 sensor connection (optional second Pt100 sensor), 5.7" industrial color TFT touchscreen
  • Industries: aerospace and automotive
  • Applications for temperature control of test specimens: DC/DC converters| inverters, electric motors, pumps & pump drives, electronic components, batteries, charging systems, coupling components, airbags, injection nozzles, and other components
  • Perfectly simulates environmental conditions
  • Specifications:
  • Heating capacity for 208V/3PPE/60Hz (9420452.16): 5.5 kW (PRESTO A45); Speak to a product specialist about additional voltage versions
  • Cooling capacity up to 3.5 kW
  • Analog connections, RS485, Profibus DP (optional)
  • Removable ventilation grid
  • Temperature stability ±0.05 °C ... ±0.1 °C
  • Pump pressure up to 3 bar, max. flow rate 80 l/min
  • Viscosity max: cSt 50
  • Pump capacity flow rate l/min: 0 ... 80
  • Pump capacity flow pressure psi: 1.5 ... 43.5
  • Power consumption A 23
  • Refrigerant R449A (Global warming potential 1397)
  • Filling weight g: 1050
  • Carbon dioxide equivalent: 1.46685 t
  • Sound pressure level dbA: 69
  • IP Code: IP 20
  • Integrated programmer: 8 x 60 steps
  • Absolute temperature calibration (ATC): 3-point calibration
  • Temperature values:
  • Temperature display resolution: °C 0.01
  • Working temperature range °C -45 ... +250
  • Temperature stability °C ±0.05 ... ±0.1
  • Ambient temperature °C +5 ... +40
  • Volumes:
  • Internal usable expansion volume: 7.5
  • Minimal process volume: 7.5
  • Active heat exchanger volume: 3.5
  • Features: various user levels, 100% cooling capacity, intelligent temperature control, temperature control features, eternal Pt100 sensor connection, electronically adjustable pump states or pressure value and automatic adjustment, various interfaces (integrated USB, Ethernet, RS232, SD card, and alarm off), continuous operation up to +40 °C, automatic switch-off in event of high temperature or low liquid level, environmentally friendly materials
  • Centrifugal pump (1 magnetically coupled)
  • Classification III according to DIN12876-1 enables safe operation, even with flammable fluids
  • Classification III (FL) according to DIN 12876-1 for flammable bath fluid
  • Adjustable high temperature cut-off for internal tank and for integrated expansion vessel
  • Integrated Black-Box function permits fast diagnosis by the JULABO service team
  • Available Julabo consultation and comprehensive manuals

• Manufacturer SKU: 9420452.16

• Unit of Measure: EA

• Electrical Specifications: 208-230V, 3 Ph, 60 Hz

• Weight, Product: 463 lb

• Dimensions, Product: 20.9" W x 26.2" D x 49.6" H
