3647-08
Terra Part # 3647-08
$15,264
Accessories related to Terra Part # 3647-08
47031
Fume Hood; Paramount Ductless, 72" W x 35.5" D x 56" H, Labconco, 115 V
Usually ships in 18-22 business days

Want it faster ? Read about FasTrak

Product Details
  • Advanced Filter Module with Organic Vapor Sensor
  • Aerodynamic air foil allows air to sweep the work surface for maximum containment
  • Clean-Sweep™ Air Foil pulls air from under the air foil so clean air flows continuously
  • Portability to allow sharing among several laboratories or storing when not in use
  • No outside ducting required
  • Upper dilution air supply draws air from above the work area, bathing the back of the sash with clean air
  • Conforms to these regulations: SEFA 1-2005, ASHRAE 110-95, ANSI Z9.5-2003, UL 3101-1/61010-1 and CAN/CSA C22.2 No. 1010.1

Depth: 35.5"

Hood Design: Benchtop

Frame Material: Powder-Coated Aluminum

Height: 56"

Manufactured by: Labconco

Manufacturer SKU: 6963603

Max Opening: 35" H

Model: Paramount Ductless

Sash Design: Manual/Tilt-Up

Sash Height: 23"

Type: Ductless

Width: 72"

Work Area Dimensions: 70"W x 30"D

Unit of Measure: EA

Dimensions, Product: 72" W x 35.5" D x 56" H

Dimensions, Shipping: 72" W x 35.3" D x 49" H

Electrical Specifications: 115 V, 10 A, 1,150 W, 50/60 Hz

Marks & Listings: SEFA 1, ASHRAE 110, ANSI Z9.17

Package Type: Box

Weight, Shipping: 680 lb

Buy Accessories
  1. Provides support for the full line of benchtop Labconco fume hoods or glove boxes  |  3646-53 displayed
    $1,749
    Increase Down Increase Up
  2. Features manual-closing, non-locking door(s)  |  3646-03 displayed
    $1,789
    Increase Down Increase Up
  3. Features manual-closing, non-locking door(s)  |  3646-03 displayed
    $1,924
    Increase Down Increase Up
  4. Safely stores corrosive liquids and acids  |  3649-49 displayed
    $1,980
    Increase Down Increase Up
  5. Safely stores corrosive liquids and acids  |  3649-49 displayed
    $1,980
    Increase Down Increase Up
  6. Supports loads up to 800 pounds  |  3646-04 displayed
    $3,010
    Increase Down Increase Up
  7. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,624
    Increase Down Increase Up
  8. Supports loads up to 800 pounds  |  3646-04 displayed
    $3,010
    Increase Down Increase Up
  9. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,624
    Increase Down Increase Up
  10. Safely stores corrosive liquids and acids  |  3649-73 displayed
    Cabinet; Acid Storage, 18"W x 22"D x 36.75"H, Labconco Ships Free Free shipping in contiguous USA
    $1,901
    Increase Down Increase Up
  11. Safely stores corrosive liquids and acids  |  3649-73 displayed
    Cabinet; Acid Storage, 18"W x 22"D x 36.75"H, Labconco Ships Free Free shipping in contiguous USA
    $1,901
    Increase Down Increase Up
  12. Safely stores corrosive liquids and acids  |  3649-73 displayed
    $1,957
    Increase Down Increase Up
  13. Safely stores corrosive liquids and acids  |  3649-73 displayed
    $1,957
    Increase Down Increase Up
  14. Safely stores corrosive liquids and acids  |  3649-49 displayed
    $2,178
    Increase Down Increase Up
  15. Features manual-closing, non-locking door(s)  |  3646-51 displayed
    $2,020
    Increase Down Increase Up
  16. Features manual-closing, non-locking door(s)  |  3646-03 displayed
    $2,082
    Increase Down Increase Up
  17. Supports loads up to 800 pounds  |  3646-09 displayed
    $3,317
    Increase Down Increase Up
  18. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,601
    Increase Down Increase Up
  19. Supports loads up to 800 pounds  |  3646-09 displayed
    $3,379
    Increase Down Increase Up
  20. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,673
    Increase Down Increase Up
  21. Supports loads up to 800 pounds  |  3646-04 displayed
    $3,498
    Increase Down Increase Up
  22. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,782
    Increase Down Increase Up
  23. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,551
    Increase Down Increase Up
  24. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,917
    Increase Down Increase Up
  25. Supports loads up to 800 pounds  |  3646-04 displayed
    $2,551
    Increase Down Increase Up
  26.  |  3647-01 displayed
    $304
    Increase Down Increase Up
  27.  |  3647-02 displayed
    $462
    Increase Down Increase Up
  28. Filter; Ammonia Carbon, for Paramount Ductless Enclosures, 18"W x 15"D x 1.5"H
    $397
    Increase Down Increase Up
  29. Filter; Formaldehyde Carbon, for Paramount Ductless Enclosures,18"W x 15"D x 1.5"H
    $485
    Increase Down Increase Up
  30. Filter; Mixed Carbon, for Paramount Ductless Enclosure
    $424
    Increase Down Increase Up
  31. Used to support a variety of Labconco enclosures  |  3646-24 displayed
    Work Surface; Solid, 72" W x 29" D, Epoxy Resin, Labconco Ships Free Free shipping in contiguous USA
    $2,129
    Increase Down Increase Up
  32. Used to support a variety of Labconco enclosures  |  3646-24 displayed
    $3,013
    Increase Down Increase Up
  33.  |  3647-69 displayed
    $2,228
    Increase Down Increase Up
  34. Work Surface; 72" W x 29" D, Stainless Steel, Spillstopper, Labconco
    $2,228
    Increase Down Increase Up
  35. Detector Tubes; Formaldehyde
    Detector Tubes; Formaldehyde Ships Free Free shipping in contiguous USA
    $130
    Increase Down Increase Up
  36. Detector Tubes; Acid Gas, 20"W x 2"D x 2"H
    Detector Tubes; Acid Gas, 20"W x 2"D x 2"H Ships Free Free shipping in contiguous USA
    $470
    Increase Down Increase Up
  37. Detector Tubes; Ammonia, 20"W x 2"D x 2"H
    Detector Tubes; Ammonia, 20"W x 2"D x 2"H Ships Free Free shipping in contiguous USA
    $106
    Increase Down Increase Up
  38. Replacement Bag-In/Bag-Out Bag  |  3646-44 displayed
    Syringe Pump Kit; Gas Detection, Labconco Ships Free Free shipping in contiguous USA
    $45
    Increase Down Increase Up
  39. Warranty; 1 Year, Labconco
    Request Quote
    Increase Down Increase Up

  • Video by Labconco which provides instructions on replacing dirty filters on a ductless laminar air flow enclosure Filter Replacement - Labconco Paramount Ductless Enclosure
  • Paramount Ductless Enclosure with Model Ductless Enclosure
Video by Labconco which provides instructions on replacing dirty filters on a ductless laminar air flow enclosure

Features and Benefits

Learn More: Fume Hoods

Ductless Exhaust Airflow Diagram

The blower pulls air into the Paramount ductless enclosure through the sash opening, along which curved airfoils eliminate "rolling" and ensure uniform airflow to the rear baffle. Air travels up and passes through the filters before returning to the surroundings.

Smart-Flow™ Airflow Monitor

The LCD display shows the equipped filter types, the status of the filters, and airflow face velocity. On/off buttons are provided to toggle the blower and light fixture. All settings are programmable and can be electronically locked for security.

Dedication to Business Ethics

Terra is committed to conducting business according to the highest standard of professional ethics and conduct. To review Terra’s ethics code, please visit: https://www.terrauniversal.com/ethics-policy/
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Labconco Solid Work Surface

    Solid black epoxy work surfaces are chemical resistant and feature a "dished" surface to contain spills. 304-grade stainless steel work surfaces with 1"-deep front spill trough are also available.
  • Telescoping Base Stand with Fixed Feet

    Tubular, epoxy-coated steel frame base stands are adjustable to eight height positions in 1" increments from 27.5" to 34.5"; used with Labconco BSCs, hoods and enclosures
  • Hydraulic Lift Base Stand

    Electric height adjustment from 25.5" to 33.5" ideal for operators of varying heights and wheelchair-bound users; compatible with Labconco BSCs, hoods and enclosures
  • Labconco Solo Hydraulic Lift Base Stand

    The SoLo Hydraulic Lift Stand is designed to make Labconco's ductless hoods portable, allowing the hood to be easily transferred throughout the facility. The remote-controlled lift allows the hood to be lowered when moving through standard-height doorways.
  • Labconco Stackable Filters for Chemical Vapors

    Labconco offers seven filter types for use with the Paramount Ductless Enclosure: Organic Vapor, Acid-Sulfur, Ammonia-Amine, Formaldehyde, Mixed Bed Carbon, Radioisotope, and HEPA filtration.
