Worldwide Pricing and Secure Global Shipping Available!
Select Product
Voltage

Type

Width

Depth

Height

Shield Type

Manufacturer SKU

Terra Part #Price Ships in
115 V Ducted 48" 37.7" 95" Vertical 112417002 3651-68 $12,441 40-44 Days2
115 V Ducted 48" 43.7" 95" Vertical 112427002 3651-69 $13,236 40-44 Days3
115 V Ducted 48" 55.7" 95" Vertical 112437002 3651-70 $14,682 40-44 Days4
115 V Ducted 60" 37.7" 95" Vertical 112517002 3651-71 $14,009 40-44 Days5
115 V Ducted 60" 43.7" 95" Vertical 112527002 3651-72 $14,777 40-44 Days6
115 V Ducted 60" 55.7" 95" Vertical 112537002 3651-73 $16,236 40-44 Days7
115 V Ducted 72" 37.7" 95" Vertical 112617002 3651-74 $15,543 40-44 Days8
115 V Ducted 72" 43.7" 95" Vertical 112627002 3651-75 $16,338 40-44 Days9
115 V Ducted 72" 55.7" 95" Vertical 112637002 3651-76 $17,771 40-44 Days10
115 V Ducted 96" 37.7" 95" Vertical 112817002 3651-77 $18,193 40-44 Days11
115 V Ducted 96" 43.7" 95" Vertical 112827002 3651-78 $18,985 40-44 Days12
115 V Ducted 96" 55.7" 95" Vertical 112837002 3651-79 $20,411 40-44 Days13
115 V Ducted 96" 37.7" 95" Horizontal 112816002 3651-80 $17,127 40-44 Days14
115 V Ducted 96" 43.7" 95" Horizontal 112826002 3651-81 $17,906 40-44 Days15
115 V Ducted 96" 55.7" 95" Horizontal 112836002 3651-82 $19,312 40-44 Days16
115 V Ducted 120" 37.7" 95" Horizontal 112016002 3651-83 $20,160 40-44 Days17
115 V Ducted 120" 43.7" 95" Horizontal 112026002 3651-84 $20,939 40-44 Days18
115 V Ducted 120" 55.7" 95" Horizontal 112036002 3651-85 $22,344 40-44 Days19
115 V Ducted 144" 37.7" 95" Horizontal 112116002 3651-86 $23,216 40-44 Days20
115 V Ducted 144" 43.7" 95" Horizontal 112126002 3651-87 $23,988 40-44 Days21
115 V Ducted 144" 55.7" 95" Horizontal 112136002 3651-88 $25,394 40-44 Days22
115 V Ducted 192" 37.7" 95" Horizontal 112216002 3651-89 $29,278 40-44 Days23
115 V Ducted 192" 43.7" 95" Horizontal 112226002 3651-90 $30,056 40-44 Days24
115 V Ducted 55.7" 95" Horizontal 112236002 3651-91 $31,469 40-44 Days25
Voltage
Type
Width
Depth
Height
Shield Type
Manufacturer SKU
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

* *
*See discounts and promos in cart Web-exclusive discount applies only to quotes/orders placed directly on our website; not valid for phone, email, or other ordering methods.
*includes online discount applied to web quotes/orders only Web-exclusive discount applies only to quotes/orders placed directly on our website; not valid for phone, email, or other ordering methods.
Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • Aerodynamic air foils and bypass airflow openings allow the hood to be operated at low face velocities (down to 60 fpm)
  • Low face velocities provide energy savings, lower noise levels, and have less of an impact on sensitive operations
  • Opti-Zone Baffle perforations concentrate exhaust airflow within the working areas where fumes are likely to be produced
  • Vertical-rising sashes glide within steel tracks, operated via a cable pulley system
  • Chemical-resistant, fiberglass-reinforced panel liner and baffle plate with flame spread index less than 25, per ASTM E84
  • All models are preconfigured for installation of water/gas fixtures and duplex outlets using Labconco’s kits
  • Specific models are available with basic service fixtures preinstalled, with conversion possible to air or vacuum
  • Powder-coated steel exhaust collars are provided (12.81" ID)
  • Cord-Keeper slots, located on either side of the sash opening, for tucking power cables out of the way
  • Optional horizontal-sliding sash available on 8’ or wider models for increased opening height up to 73.5"
  • Includes vapor-proof, fluorescent light fixture with separate power switch
  • ADA-compliant controls
  • Requires connection to exhaust system with remote blower (sold separately)

  • Labconco Protector XL Labconco Protector XL
Labconco Protector XL
Features & Benefits

Features & Benefits

Learn More: Fume Hoods

Protecting Personal Information

Terra is committed to ensuring that our customer’s personal information is secure. In order to prevent unauthorized access or disclosure, Terra has developed procedures to safeguard and secure information collected online and offline.

Long-Standing Industry Expertise

For 50 years, Terra has served the life science, academic research, pharmaceutical, biotechnology, medical device, semiconductor and aerospace markets. We intimately understand the cGMP, GLP, ISO, ASTM , IEST and OSHA requirements.

Top-Tier Clients

Terra’s key customers include some of the largest research labs, production facilities and universities in the world

Catalog of CE-Marked Products

Terra offers over 1,700 CE-marked products configured for international voltage requirements
Available Accessories
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Labconco Spillstopper Work Surfaces

    These dished work surfaces are made of corrosion-resistant epoxy resins for durability and a smooth finish. Pass-through holes for venting and plumbing are predrilled into the rear portion of the surface (cut-outs for cup-sinks are optional).
  • Labconco Fiberglass Blower

    Constructed with a 304 stainless steel one-piece liner with coved corners, Protector Stainless Steel Radioisotope Hoods have no joints, crevices or cracks. Units effectively contain radiochemicals.
  • Remote Blower

    Labconco offers energy-efficient remote blowers with an ECM motor that handle airflow from 250 CFM to 3200 CFM satisfying various exhaust requirements
  • Labconco Digital Airflow Monitor

    The Guardian 1000 Airflow Monitor measures the air speed within the fume hood and alerts users to unsafe conditions.
