Rotary Evaporator Accesories
by IKA®

RV 10.1000 Glassware diagonal Evaporation Flasks and more Distilling spiders
RV 10.1000 Glassware diagonal Evaporation Flasks and more Distilling spiders

IKA offers a comprehensive selection of distillation glassware and accessories for use in conjunction with IKA RV 8 and RV 10 Rotary Evaporators. Distillation glassware, condensers, flasks, cylinders and spiders are made of high-quality borosilicate glass. Shatterproof, coated models offer the added safety of preventing glass from breaking.

  • Distillation Glassware: vertical and diagonal glassware units for standard distillation are required with RV 8 FLEX and RV 10 FLEX Rotary Evaporators
  • Condensers: vertical condensers, vertical-intensive condensers with manifold (option for cut-off valve) and dry ice condensers efficiently feed solvent via the PTFE inlet tube
  • Evaporation Flasks: NS 24/40 joint flasks are available in seven volume capacities
  • Receiving Flasks: KS 35/20 joint flasks in six volume capacities are available in standard or coated shatterproof units
  • Powder Flasks: NS 24/40 joint flasks in three volume capacities prevent powder build-up on flask wall
  • Evaporation Cylinders and Foam Break: NS 24/40 joint units in two volume capacities retrieve viscous substances and stops foam from entering receiving flask
  • Distilling Spiders: NS 24/40 spiders with choice of 6, 12 and 20 distilling sleeves or five flask model in two capacity sizes
  • Laboratory Equipment Control Software: multi-purpose software measures, controls and regulates up to 64 devices simultaneously via one PC
  • Heating Bath and Accessories: used for water and oil applications, units optimize bath volume and guarantee fast heating; includes integrated dry-run control
  • Vacuum Pumps: chemical resistant units are appropriate for a variety of dry, oil-free applications

Ordering Information


Distillation Glassware for IKA Rotary Evaporators


RV 10.900 Glassware vertical




RV 10.1000 Glassware diagonal
IKA
Part #
Description Shatterproof
Coating
Cat. # Price
0003842500 RV 10.900 Glassware vertical No 6924-22 $ 1,150
0003842600 RV 10.910 Glassware vertical coated
Coating provides optimal shatter protection for enhanced safety
Yes 6924-23 $ 1,189
0003842700 RV 10.1000 Glassware diagonal No 6924-24 $ 993
0003842800 RV 10.1010 Glassware diagonal coated
Coating provides optimal shatter protection for enhanced safety
Yes 6924-25 $ 1,733
  • For use with IKA RV 8 and RV 10 Rotary Evaporators
  • Material: borosilicate glass
  • Includes two flasks
  • Required glassware for RV 8 FLEX and RV 10 Flex models
  • NOTE: distillation glassware included in RV 8 and RV 10 rotary evaporators except for FLEX models

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Condensers for IKA Rotary Evaporators


IKA
Part #
Description Cat. # Price
3741000 RV 10.3 Vertical-intensive condenser with manifold 6924-26 $ 1,586
3741100 RV 10.30 Vertical-intensive condenser with manifold, coated 6924-27 $ 2,277
  • Condenser type: vertical-intensive
  • Material: borosilicate glass 3.3
  • Efficient condensation with double jacket and manifold
  • Solvent to be distilled can be continuously fed in at the distributor using the PTFE inlet tube
  • #3741100 coated for enhanced shatter protection

IKA
Part #
Description Cat. # Price
3742000 RV 10.4 Dry Ice Condenser 6924-28 $ 1,656
3742100 RV 10.40 Dry Ice Condenser, coated 6924-29 $ 1,827
  • Distills low-boiling solvents
  • Material: borosilicate glass 3.3 and coated with SURLYN
  • Dry ice condenser for distilling low-boiling solvents
  • Solvent to be distilled can be continuously fed in at the distributor using the PTFE inlet tube
  • No cooling water required when cooling by dry ice
  • #3742100 coated for shatter protection; Temperature range: -30 up to +60°C

IKA
Part #
Description Cat. # Price
3743000 RV 10.5 Vertical condenser with manifold and cut-off valve for reflux distillation 6924-30 $ 1,773
3743100 RV 10.50 Vertical condenser with manifold and cut-off valve for reflux distillation, coated 6924-31 $ 2,005
  • Stops valve for reflux distillation
  • Material: borosilicate glass 3.3 and coated with SURLYN
  • Solvent to be distilled can be continuously fed in at the distributor using the PTFE inlet tube
  • #3743100 coated for shatter protection; Temperature range: -30 up to +60°

IKA
Part #
Description Cat. # Price
3744000 RV 10.6 Vertical-intensive condenser with manifold and cut-off valve for reflux distillation 6924-32 $ 2,039
3744100 RV 10.60 Vertical-intensive condenser with manifold and cut-off valve for reflux distillation, coated 6924-33 $ 2,239
  • Stops valve for reflux distillation
  • Material: borosilicate glass 3.3 and coated with SURLYN
  • Included condensate cover and outlet channel prevent condensate from coming in contact with seal
  • Solvent to be distilled can be continuously fed in at the distributor using the PTFE inlet tube
  • #3744100 coated for shatter protection; Temperature range: -30 up to +60°C

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Evaporation Flasks NS 24/40 for IKA Rotary Evaporators

Evaporation Flask

IKA
Part #
Description Cat. # Price
3845300 RV 10.2007 Evaporation Flask, (NS 24/40, 50 ml) 6924-34 $ 47
3845400 RV 10.2008 Evaporation Flask, (NS 24/40, 100 ml) 6924-35 $ 54
3845500 RV 10.2009 Evaporation Flask, (NS 24/40, 250 ml) 6924-36 $ 80
3845600 RV 10.2010 Evaporation Flask, (NS 24/40, 500 ml) 6924-37 $ 83
3845700 RV 10.2011 Evaporation Flask, (NS 24/40, 1000 ml) 6924-38 $ 86
3845800 RV 10.2012 Evaporation Flask, (NS 24/40, 2000 ml) 6924-39 $ 130
3845900 RV 10.2013 Evaporation Flask, (NS 24/40, 3000 ml) 6924-40 $ 202
  • Material: Borosilicate glass
  • Adapter: NS 24/40
  • Available in seven volume capacities

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Receiving Flasks KS 35/20 for IKA Rotary Evaporators


Receiving Flask

IKA
Part #
Description Cat. # Price
3742200 Receiving Flask (KS 35/20, 100 ml) 6924-41 $ 77
3742300 Receiving Flask (KS 35/20, 250 ml) 6924-42 $ 80
3742400 Receiving Flask (KS 35/20, 500 ml) 6924-43 $ 81
3742500 Receiving Flask (KS 35/20, 1000 ml) 6924-44 $ 84
3742600 Receiving Flask (KS 35/20, 2000 ml) 6924-45 $ 138
3742700 Receiving Flask (KS 35/20, 3000 ml) 6924-46 $ 258
3743200 Receiving Flask, coated (KS 35/20, 100 ml) 6924-47 $ 162
3743300 Receiving Flask, coated (KS 35/20, 250 ml) 6924-48 $ 179
3743400 Receiving Flask, coated (KS 35/20, 500 ml) 6924-49 $ 206
3743500 Receiving Flask, coated (KS 35/20, 1000 ml) 6924-50 $ 218
3743600 Receiving Flask, coated (KS 35/20, 2000 ml) 6924-51 $ 265
3743700 Receiving Flask, coated (KS 35/20, 3000 ml) 6924-52 $ 338
  • Material: Borosilicate glass
  • Joint: KS 35/20
  • Available coated or uncoated
  • Coated models offer enhanced shatter protection
  • Available in six capacity sizes

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Powder Flasks NS 24/40 for IKA Rotary Evaporators


Powder Flask
IKA
Part #
Description Cat. # Price
3847200 Powder Flask (NS 24/40 500 ml) 6924-53 $ 187
3847300 Powder Flask (NS 24/40 1000 ml) 6924-54 $ 202
3847400 Powder flask (NS 24/40 2000 ml) 6924-55 $ 247
  • Available in 500, 1000 and 2000 ml capacity
  • Dries powdered substances
  • Helps to avoid powders from accumulating on wall of flask
  • Optimizes powder drying applications
  • Material: borosilicate glass
  • Joint: NS 24/40

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Evaporation Cylinders NS 24/40 for IKA Rotary Evaporators


Evaporation Cylinder
IKA
Part #
Description Cat. # Price
3848200 Evaporation Cylinder (NS 24/40 500 ml) 6924-56 $ 706
3848300 Evaporation Cylinder (NS 24/40 1500 ml) 6924-57 $ 936
  • Available in 500 and 1500 ml capacity
  • Material: borosilicate glass
  • Joint: NS 24/40
  • Evaporation Cylinder retrieves viscous substances

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Foam Break NS 24/40 for IKA Rotary Evaporators


Foam Break
IKA
Part #
Description Cat. # Price
3848700 Foam Brake (NS 24/40) 6924-58 $ 159
  • Material: borosilicate glass
  • Joint: NS 24/40
  • Stops foam from entering receiving flask
  • Requires extension plate #RV 10 30000 when using a 3L evaporation flask

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Distilling Spiders Ns 24/40 for IKA Rotary Evaporators


Distilling Spiders Ns 24/40
IKA
Part #
Description Cat. # Price
3849300 Distilling spider with 6 distilling sleeves (NS 24/40) 6924-59 $ 657
3849400 Distilling spider with 12 distilling sleeves (NS 24/40) 6924-60 $ 1,047
3849500 Distilling spider with 20 distilling sleeves (NS 24/40) 6924-61 $ 1,465
  • Available in 6, 12 or 20 distilling sleeves
  • Includes distilling sleeves
  • Material: borosilicate glass
  • Joint: NS 24/40

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Distilling Spiders Ns 24/40 for IKA Rotary Evaporators (includes 5 flasks)


Distilling Spider
IKA
Part #
Description Cat. # Price
3849800 Distilling spider with 5 flasks 50 ml (NS 24/40) 6924-62 $ 865
3849900 Distilling spider with 5 flasks 100 ml (NS 24/40) 6924-63 $ 869
  • Available in 50 and 100 ml capacities
  • Material: Borosilicate glass
  • Joint: NS 24/40
  • Select items include flasks for simultaneous distillation

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Laboratory Equipment Control Software for IKA Instruments


Networks up to 64 devices

For use with RV 10 Digital and RV 10 Control Rotary Evaporators


IKA
Part #
Description Cat. # Price
4720000 Labworldsoft® 6924-64 $ 224
  • Automates all IKA laboratory equipment with an advanced multi-purpose software program
  • Measures, controls and regulates equipment
  • Networks up to 64 devices simultaneously via one PC
  • Multiple language support (up to 10 languages)
  • Integrated license management; Online firmware
  • XML support for importing / exporting older configuration files
  • Windows 7 support and up-to-date online help
  • Features: Network Monitoring, Controlling, Recording, Evaluating, Exporting, Storing
  • Compatible with: Windows 2000, Windows XP, Windows Vista, Windows 7 and Windows 8
  • Click price for complete features of Labworldsoft® software

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Heating Bath and Accessories for IKA Rotary Evaporators


HB 10 Universal Heating Bath with built-in dry-run control
IKA
Part #
Description Cat. # Price
4068001 HB 10 Universal Heating Bath 6924-65 $ 1,319
  • For use with IKA rotary evaporators
  • For water and oil applications, the HB 10 heating bath also comes with a built in dry- run control
  • Stops heating the bath if no medium is present
  • Universal use for both water and oil
  • Ergonomically designed handles
  • Safety temperature cut off and integrated dry-run control
  • Lock function prevents accidental change of set conditions
  • Micro-controller temperature control
  • Accuracy +/-1 Kelvin; Heater power 1300 Watt
  • Optimized bath volume guarantees fast heat-up

HB 10.1 Shield for heating bath HB 10


IKA
Part #
Description Cat. # Price
3641800 HB 10.1 Shield for heating bath HB 10 6924-66 $ 276
  • For use with HB 10 Universal Heating Bath
  • Protects operator against splashes of hot liquid

HB 10.2 Protective cover

IKA
Part #
Description Cat. # Price
3641000 HB 10.2 Protective cover 6924-67 $ 1,006
  • Protects user from hot liquid splashes and flask breakage
  • Essential accessory if working without an extractor hood

See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Vacuum Pumps for IKA Rotary Evaporators


MVP 10 Basic Vacuum Pump

IKA
Part #
Description Cat. # Price
3980001 MVP 10 Basic Vacuum Pump 6924-68 $ 1,629
  • For dry, oil-free applications
  • Material: parts in contact with gas made of chemical resistant PTFE or PTFE compounds
  • Slimline, compact design
  • Easy to maintain and long service life
  • Chemical resistant diaphragm
  • Click price to see full product specs

N 920 KT.29.18 Membrane Vacuum Pump
IKA
Part #
Description Cat. # Price
3919100 N 920 KT.29.18 Membrane Vacuum Pump 6924-69 $ 4,589
  • 100% oil-free pumping ensures pure transfer, evacuation and compression
  • KNF stabilization system allows high suction speed even in the low-vacuum range
  • For slightly aggressive or corrosive gases and vapors
  • Protects operator against splashes of hot liquid
  • Maintenance-free, environmentally friendly and gastight (leakage rate approx. 6 x 10-3 mbar x l/s, not tested in serial production)
  • Click price to see full product specs

LVS 105 T-ef Vacuum Pump System
IKA
Part #
Description Cat. # Price
4067800 LVS 105 T-ef Vacuum Pump System 6924-70 $ 3,572
  • Compact, dry-running, chemical resistant pump system
  • Fully automatic  with built-in solvent library
  • Graphic display; User-friendly operation; Optimal stability; Quick and easy maintenance
  • Close to 100% solvent recovery
  • Equipped with a speed regulated vacuum controller and a chemical resistant diaphragm pump
  • Pumping speed can be precisely controlled
  • Click price to see full product specs
See:Distillation Glassware, Condensers, Evaporation Flasks, Receiving Flasks, Powder Flasks, Evaporation Cylinders and Foam Breaks, Distilling Spiders, Laboratory Equipment Control Software, Heating Bath and Accessories and Vacuum Pumps

Related Products

Click to leave a message. 24-hour sales and tech phone support, M - F
Call a Terra Evaporator specialist direct
Hours: 5:30 - 17:30 M-F
(your local time)
Go to...
Go To
TerraUniversal.com
