- Available Certified ISO Grade Designs: ISO 6, ISO 7, ISO 8
- Dehumidification system supplies the room with hot, dry air that is capable of maintaining a temperature of 90 °F (32 °C) and a drying capacity of 22 lbs/hr at ideal conditions of 68 °F (20 °C) at 60% RH
- Suited for EV battery assembly, adhesive curing, PC board drying, or filter assembly
- 3.5" PLC touchscreen allows control for drying levels, meters for allotted dehumidifying time, and alarm functions
- Included filters clean the air prior to entering the unit and will extend the use of the rotor
- Hot, dry air can reach a maximum temperature of +248 °F (120 °C), but changes in atmospheric pressure can affect the temperature of emitted air. Specifications are based on ideal conditions.
• Height: 7.5'
• Depth: 9'
• Width: 6'
• Certified ISO Grade Design: ISO 6
• Available Certified ISO Grade Designs: ISO 6, ISO 7, ISO 8
• Number of Doors: 1 Door
• Process Air Flow: 824 CFM
• Drying/Humidifying Capacity: 22 lb/hr
• Temperature Range: 90 °F to +248 °F
• Unit of Measure: EA
