• Type: Vacuum Pick-up
• Application: Wafer Handling
• Configuration: Vacuum Pick-up
• Features: Pen Style
• Unit of Measure: EA
Pen-Vac Kit; Non-Marking Static Dissipative Cup Material
Read more
Warranty: 90 Days after Receipt of Produ
Print
Want a quote quickly ?
Submit a QuickQuote request- Each kit includes: (1) vacuum pen, (4) probes and (4) cups
- Material is Non-Marking Black Static Dissipative
• Type: Vacuum Pick-up
• Application: Wafer Handling
• Configuration: Vacuum Pick-up
• Features: Pen Style
• Unit of Measure: EA
• Electrical Specifications: None
• Dimensions, Product: 0" W
• Weight, Shipping: 2 lb
• Dimensions, Shipping: 0" W
• Package Type: Crate
Other products you may find relevant
Some ship in 0 - 10 days
Some ship in 0 - 2 days
Portable Wire-Bond Strength Tester- High-Precision Microelectronics Tweezers for Every Need!
- Squeegee Blades for Microelectronics Printing
- Porta-Wand Kit with 4" Wafer Tip
The portable Wire-Bond Strength Tester performs accurate, reliable wire-bond tests in conformance with MIL-STD 883C | 9101-00 displayed Portable Wire-Bond Strength Tester Portable Wire Bond Strength Tester performs accurate, reliable destructive and nondestructive wire bond testing in conformance with MIL-STD 883C; variety of pull gauges available.
Full range of high-precision tweezers includes models for wafers, chips and other sensitive parts. Shown: Swiss-made tapered tweezer with very fine points, 400 | 9302-47 displayed High-Precision Microelectronics Tweezers for Every Need! Full range of high-precision tweezers includes models for wafers, chips and other sensitive parts. Shown: Swiss-made tapered tweezer with very fine points, 400 series (magnetic) stainless steel for die attaching or wire bonding in microelectronic assembly.
Polyurethane squeegee blades come in either hardnesses; precision-molded edges are suitable for precision microelectronics printing | 8101-01 displayed Squeegee Blades for Microelectronics Printing Polyurethane squeegee blades come in either hardnesses and can be cut to correct print lengths; precision-molded edges are suitable for precision microelectronics screen printers.
Portable, self-contained, continuous vacuum system provides reliable wafer handling | 6422-38 displayed Porta-Wand Kit with 4" Wafer Tip This portable, continuous-vacuum system is ideal for handling wafers, disk media or other delicate flat media; ESD-safe, cleanroom-compatible device lifts over 500g.
Features and Benefits
Pen-Vac
Print Copy Copied
Pen-Vacâ„¢
- Lifts objects weighing up to 100 grams
- Features a totally self-contained vacuum source—no external power supply needed
- Compact design and light weight make it convenient to use anywhere you need vacuum pick-up
- Built-in storage compartment holds extra vacuum tips and cups
- Interchangeable vacuum cups are available in several sizes, materials
A Vacuum Pickup in Your Pocket!
The convenient, economical Pen-Vacâ„¢ is ideal for applications throughout the microelectronics manufacturing lab.
It generates its own vacuum supply—no batteries or other power source is required. Various sizes of vacuum probes are available to accommodate a wide variety of part sizes.
A minimum total order of $65 is required for Pen-Vac items.
Pen-Vacâ„¢ Kit
Includes a vacuum pen with 4 probes and cups:- Brushed aluminum body
- Stainless steel probe needle on aluminum hub
- Vacuum cups in several materials
- 3 angled, 0.125" (3 mm)
- 0.25" (6 mm)
- 0.375" (10 mm) cups
- 1 straight, 0.25" (6 mm) cup
Pen-Vac Kit; with Black Conductive High-Temperature Silicon Cup Material
Pen-Vac features a brushed aluminum body and stainless steel probe needle on aluminum hub. Vacuum cups black conductive high-temperature silicon.
