Product Details
Product Details
  • Available Certified ISO Grade™ Designs: ISO 6, ISO 7, ISO 8
  • Filter replacement alarm keeps your fan filter units working safely and efficiently
  • 1 Filter Replacement Alarm unit covers for all FFUs in your cleanroom
  • Receive automatic replacement alerts to avoid costly and unexpected operational interruptions
  • Prevent electrical/fire hazards caused by overworked motors pushing against overloaded HEPA filters
  • Control differential pressure set-point to adjust frequency of filter replacement
  • Includes audible buzzer with silencer that sounds when set point level is exceeded
  • Factory set to issue a warning alarm when pressure reaches twice the initial backpressure (typically 1.5"" WC), indicating need for filter replacement (adjustable 0.5"" - 2"" WC)
  • Alarm unit connects to one FFU equipped via challenge port and signals when all filters are ready to be replaced
  • TUI Logo flashes when the HEPA or ULPA filter needs to be replaced
  • Integrated Minihelic gauge displays the backpressure within the fan/filter unit
  • Monitoring system’s control box is typically mounted above the cleanroom control panel
  • Module draws power from the cleanroom PDM or can be connected to a standard 120V outlet (order power outlet cord adapter separately)"

Certified ISO Grade™ Design: ISO 6

Unit of Measure: of 1

  • Terra Universal WhisperFlow® Filter Fan Units Terra Universal WhisperFlow® Filter Fan Units
  • Cleanroom HEPA or ULPA Fan Filter Unit WhisperFlow Cleanroom HEPA Fan Filter Unit
  • Stainless Steel WhisperFlow Fan and Filter Units Stainless Steel WhisperFlow Fan and Filter Units, 2' x 4'
  • EC HEPA Fan Filter Unit Smart WhisperFlow Fan Filter Unit with EC Motor
  • Room Side Replaceable Fan Filter Units (FFUs) Room Side Replaceable WhisperFlow® Fan Filter Units (FFUs)
Terra Universal WhisperFlow® Filter Fan Units
Features & Benefits

Features and Benefits

Learn More: Filter Replacement Alarm System

Complete Project Transparency

Terra is dedicated to complete transparency on project status, shipment tracking, and installation scheduling

Complete Order Transparency

Using Terra’s OnTrak system, our customers can view real-time production updates, receive shipment notifications and track their orders until they arrive at their facility

Products Compliant With Your ISO Rating

High-capacity, durable, ISO-compliant system rated for thousands of operating hours.
Available Accessories
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Energy-Efficient Lighting

    Energy-efficient LED lighting panels and strips help to lower electrical costs and minimize heat build-up in temperature-controlled environments.
  • Power Distribution Modules for Cleanroom FFUs and Lights

    UL-listed power distribution modules include all breakers, transformers and other electrical components for FFU/light connections; allows fast addition or relocation of FFUs or lights without the need for rewiring.
  • Ionizing Bar; 22"L, with Installation Kit, for 24 x 24 Fan/Filter Unit

    Ionizing bar, mounted to Fan/Filter Unit, provides a balanced stream of ions to the work area below to neutralize static charge and prevent electro-static discharge; 22" bar shown installed on 2' x 2' FFU.
  • Night Service Saves Energy, Extends Filter Life!

    Night service switch, shown mounted on Modular Hardwall Cleanroom panel, puts FFUs in low-energy mode during off-hours; saves 25% of fan operating costs and extends filter life.
  • Filter Replacement Alarm

    The filter replacement alarm monitors filter backpressure and issues an alarm when filter needs replaced (requires selection of fan filter unit with challenge port, order separately).
  • Cord Adapter, MIN4 PL to 16AWG Power Cord for Terra Fan/Filter Unit

    Four-pin power cord adapter for fan/filter unit allows connection to standard 120VAC/60Hz power receptacle.
  • FFU Mounting Frame; Stainless Steel

    Stainless steel Fan Filter Unit (FFU) mounting frame supports FFU on drywall or other rigid ceiling material, viewed from above ceiling panel (FFU not included).
  • Fan Filter Unit Control System

    Provides room-by-room monitoring and control of Smart WhisperFlow FFUs to maintain target pressure differentials for ISO classification; temperature, humidity and particle monitoring and data logging, as well as dynamic fan set-point control, also available.
  • Filter Covers Allow Ceiling Wash-Down

    Ceiling panel covers allow wash-down and sterilization of cleanroom walls and ceilings without damage to filter medium; requires BioSafe glass or stainless steel wall panels, which stand up to biocides.
  • Challenge Port for Fan Filter Unit

    Challenge port for Fan/Filter Units simplifies filter leak testing and connection of Filter Backpressure Alarm (shown with optional pressure gauge; must be ordered with FFU).
  • Safely Mount FFU’s Above Floor for Horizontal Laminar Airflow

    The portable FFU base stand can be easily positioned to supply Class 100 horizontal laminar flow into a room or enclosure. It can also be positioned next to sensitive equipment/materials that are mounted close to the floor.
