Select Product

Material

Capacity

Temperature Range

Convection Type

Voltage

Manufacturer SKU

PriceShips in
Epoxy-Coated Steel 19.3 cu. ft. Ambient +15°C to 40°C Mechanical 120 V SRI20P $6,20310-16 Days
Epoxy-Coated Steel 6.5 cu. ft. Ambient +15°C to 40°C Mechanical 120 V SRI6P $4,19515-21 Days
Epoxy-Coated Steel 3 cu. ft. Ambient +15°C to 40°C Mechanical 120 V SRI3P $3,94515-21 Days
Material
Capacity
Temperature Range
Convection Type
Voltage
Manufacturer SKU
Item ordered before. Click on bagde to see the order.
Demo Available
Some ship in:
Usually Ships in:
Item is in stock and ready for immediate shipping
Free shipping in contiguous USA
Select product to see details

Product Details

• Energy-efficient B.O.D. Thermoelectric Cooled Incubators by SHEL LAB are designed for use in sewage and wastewater testing

• Peltier cooled incubators meet APHA requirements

• For biochemical oxygen demand measurements of water samples

• P.I.D. Temperature Control

• LED display of temperature set point and current chamber temperature

• Mechanical convection for uniform air distribution

• Fan assisted forced air circulation

• Independent over temperature thermostat

• Alarms: over temperature and door ajar

• Reduces room air conditioning loads by 75%

• Uses 70% less energy than compressor based incubators

• Safety Certifications UL 61010-1, EN 61010-1, CSA 61010-1, CE

• NRTL certified

Incubators

  • BODThermoelectric Peltier Cooled Incubator sr16p BOD Thermoelectric Peltier Cooled Incubator
  • BODThermoelectric Peltier Cooled Incubator sr120p BODThermoelectric Peltier Cooled Incubator sr120p
  • BOD Thermoelectric Peltier Cooled Incubator Biochemical Oxygen Demand (B.O.D.) Incubators
BODThermoelectric Peltier Cooled Incubator sr16p
BODThermoelectric Peltier Cooled Incubator sr120p
BOD Thermoelectric Peltier Cooled Incubator

Features & Benefits

Features & Benefits

B.O.D. Incubator Features and Specs

Energy-Efficient B.O.D. Thermoelectric Cooled Incubators for Wastewater Testing

Designed with a Peltier cooling technology and an innovative microprocessor, B.O.D. Thermoelectric Cooled Incubators by Shel Lab use up to 71% less energy because eliminate the need for a refrigeration compressor. Units provide excellent temperature uniformity throughout the incubator chamber ensuring that samples are under stable temperature conditions regardless of where they are in the inner chamber. These B.O.D. incubators help water treatment plants meet American Public Health Association requirements during wastewater testing procedures.

Note: Model SRI20P received a testimonial from the Clean Water Services (a water resources management utility in Tualatin River Watershed) for the unit's "amazing temperature uniformity" and energy efficiency.
Model SRI3P SRI6P SRI20P
Capacity 3 cu. ft. (85 L) 6.5  cu. ft. (185 L) 19.3 cu. ft. (546 L)
B.O.D. Bottle Capacity 84 120 300
Internal Dims (WxDxH) 19.0 x 16.2 x 26.2 in.
(483 x 411 x 665 mm)
25.5 x 24 x 18.5 in.
(647 x 609 x 469 mm)
25.5 x 24 x 54.5 in.
(647 x 609 x 1384 mm)
External Dims (WxDxH) 23.5 x 21.0 x 33.7 in.
(597 x 534 x 856 mm)
30 x 31.5 x 33.5 in.
(762 x 801 x 851 mm)
30 x 31.5 x 69.5 in.
(762 x 801 x 1766 mm)
Electrical 115 volts, 60Hz 115 volts, 60Hz 115 volts, 60Hz
Number of Shelves 2, adjustable 2, adjustable 5, adjustable
Shelf Capacity 35 lbs. 75 lbs. 75 lbs.
Temperature Range 15°C to 30°C 15°C to 40°C 15°C to 40°C
Max. Energy Consumption 360 watts 480 watts 660 watts
Circulation Technology Forced-Air Circulation
Electrical Outlets 1
Temperature Increments 1°C
Material Interior: Aluminum
Exterior: Painted Cold Roll Steel
Shelves: Painted Mild Steel
Warranty 2-year limited warranty
