120 V Polyethylene Laminated Safety Glass 33.5" 30" 39" XPert Weigh 2 ISO 5 3644-42 51670 $13,847 20-24 Days 2
Voltage
Chamber Material
Window Material
Chamber Width
Chamber Depth
Chamber Height
Model
Number of Glove Ports
ISO Class
Item ordered before. Click on bagde to see the order.

Up to 30-day trial periods, free return shipping and on-site training available for qualified equipment.

Request demo from your product specialist or add note to your order or quote request.

Some ship in:
Usually Ships in:
Free shipping in contiguous USA
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Custom-configured product. Contact Lab Equip by phone, chat or email for a project-specific quote.
Select a product line for product summary
Product Details
Product Details
  • Available ISO Ratings: ISO 5, ISO 6, ISO 7, ISO 8
  • HEPA filtration maintains ISO Class 5 conditions in work area
  • Includes: anti-static ionizer fan, balance vibration isolator and neoprene gloves, built-in blower with speed control
  • Ideal for use in pharmaceutical, nanotechnology and biochemistry labs working with hazardous airborne particulates or powders
  • Provides a leak-tight barrier to the operator while weighing potent fine powders
  • Airborne particulate cleanliness exceeds ISO Class 5 conditions and achieves ISO Class 3 conditions
  • ¼” laminated safety glass viewing window with powder-coated steel frame and neoprene gasket
  • Included glove size: neoprene gloves size 9 ¾”
  • Interior space of main chamber: 13 cu. ft.
  • Built-in blower speed control capable of airflow from 13 CFM to 100 CFM (22.1 m³/hr. to 170 m³/hr.)
  • 0.05 ppm average tracer gas levels or less detected during perimeter scan testing
  • Vibrations less than .00015 inches (0.004 mm) displacement measured at the work surface at all airflow volumes
  • Balance stability to five decimal places on an analytical balance
  • Leak-tested with a mass spectrometer while pressurized with helium at 1 inch of water gauge

  • Protector Filtered Glove Box by Labconco
  • Labconco Protector Fiberglass Controlled Atmosphere Glove Box Labconco Controlled Atmosphere Glovebox
  • Labconco Precise Controlled Atmosphere Glovebox Labconco Precise Series Controlled Atmosphere Glove Boxes
  • Protector Combination Glove Box with Stainless Steel Lining Labconco Stainless Steel Protector Filtered Glove Boxes
  • Labconco Protector Filtered Glove Box Labconco Protector Filtered Glove Box
  • Labconco Protector Stainless Steel Double Filtered Glove Box Labconco Protector Stainless Steel Double Filtered Glove Box
  • Protector Filtered Barrier Isolator Glove Box with HEPA Filter Protector Filtered Barrier Isolator Glove Box with HEPA Filter
  • Labconco Protector Combination Glove Boxes Labconco Protector Combination Glove Boxes
  • Labconco Precise Basic Glove Box With Stand Labconco Precise Basic Glove Box
Features & Benefits

Features & Benefits

Learn More: Labconco XPert Weigh Boxes

More Information

Inlet and Outlet HEPA Filters and Ducting

The inlet and outlet HEPA filters are 99.99% efficient on 0.3 micron particulates. They also prevent contamination from entering or leaving the glove box chamber. These glove boxes are also designed to return filtered air to the laboratory. There is an optional FilterMate Portable Exhauster that may be installed via a ductwork downstream of the exhaust to adsorb low levels of organic fumes, formaldehyde, or ammonia gases. The glove boxes can also be thimble ducted and exhausted to the outside using a remote-mounted blower.

Built-In Blower with Speed Control

The built-in blower enables airflow from 13 CFM to 100CFM (22.1 m³/hr to 170 m³/hr). It pulls air through the inlet HEPA filter and discharges HEPA-filtered air back into the laboratory through the top of the box. The negative pressure operation ensures that all internally contaminated air passes through the exhaust HEPA filter before returning to the laboratory.

Glove Box Construction

XPert Weigh boxes are made of a one-piece molded, medium-density polyethylene liner (shell). This provides a durable surface that is resistant to chemical corrosion, physical damage and the coved corners simplify cleaning. Located above the glove box shell is a dry-powder epoxy-coated steel superstructure for utility placement. This superstructure has superior corrosion resistance. Additionally, the glove box contains a laminated safety glass viewing window, 26.4"W x 12.5" H (671 mm x 318 mm) with a powder-coated steel frame and a neoprene gasket that provides a tight seal. The window is removable which allows for placement of large equipment inside the glove box. The XPert Weigh box also comes with space-saving acrylic inner and outer transfer chamber doors. These doors pivot upward to save space and are counterbalanced and equipped with quick latches.

XPert-Weigh Boxes Also Feature:

An interior ceiling-mounted electrical receptacle with 5 amp maximum (115Volt models) or 2 amp maximum (230 Volt models) circuit load that provides power for instrument use within the glove box. The transfer chamber, with internal dimensions of 11" x 12" (279 mm x 305 mm), has an interlocking flat shelf of dry powder-coated epoxy steel to permit objects to stand upright. There is a large internal work area to allow for 13 cubic feet (0.4 m³) of interior space within the main chamber, 22 watt- fluorescent lamp, and control switches for the fluorescent light and innermost interior receptacle.

Products Compliant With Your ISO Rating

Provide Terra with your desired ISO rating. We will tailor the product to meet your rating and supply a certificate of compliance appended to your invoice, to be included in your compliance package. All certificates are archived in Terra's system for quick retrieval.
Available Accessories
Popular Accessories
For a full list of accessories, select a product then click Choose Accessories on that product page.
  • Adjustable Height Mobile Stand for Labconco Glove Boxes

    Stationary and mobile adjustable-height stands provide stable support for 2- or 4-port Protector and Precise Glove Boxes (mobile stand shown with 5" casters)
  • Latex Gloves, Size 9-3/4, one pair, for Labconco Glove Boxes

    Choose latex gloves for optimal dexterity, gloves also available in neoprene, butyl and hypalon, with one or two-piece configurations.
  • Labconco FilterMate Portable Exhauster

    Labconco's portable exhaust system filters hazardous vapors and powders as they are exhausted from an enclosure, allowing safe relesae into the surrounding environment.
  • Vibration Isolator, for Labconco Glove boxes

    Balance Vibration Isolator for Labconco Glove Boxes minimizes vibration within the chamber improve accuracy of sensitive analytical balances; includes a thick marble slab, 4 isolator pads and a 304 stainless steel protective top cover
