Product Details
- Available Certified ISO Grade Designs: ISO 7, ISO 8
- Benchtop laminar flow hood provides HEPA filtered Class 10,000 (ISO 7) mini cleanroom environment
- Bio-tech HEPA enclosure suitable for genomics, cell biology, mushroom cultivation
- Affordable laminar flow clean bench is portable, durable, and chemical resistant
- Chemical resistant polypropylene enclosure resists common acids, solvents, and disinfectants
- Cleanroom-grade system includes HEPA filter (ISO 5/Class 100) or optional ULPA (ISO 4/Class 10)
- Convert any workspace into a mini cleanroom environment with Terra's ValuLine® benchtop laminar flow hood.
- Polypropylene benchtop laminar flow hood includes an integrated work surface, enclosure cabinet, and HEPA fan filter unit.
- Positive pressure laminar flow hood with chemical resistant enclosure provides ideal conditions for science and laboratory applications including wet chemical use, contamination sensitive cell cultures, mushroom cultivating, and other sterile product or specimen handling.
- A 3-speed switch allows low, medium, and high settings with an average airflow velocity of 90+ feet per minute at 640+ CFM.
- UL-listed Fan Filter Units (FFUs) are manufactured to the highest standards to reduce the risk of damage, injuries, and electrical hazards.
- See performance data and submittal sheets for additional information on fan filter unit.
- Includes High Efficiency Particulate Air (HEPA) Filter: 99.99% efficient at 0.3µm particle diameter. Optional Ultra-Low Particulate Air (ULPA) Filter: 99.999% efficient at 0.12µm particle diameter.
- Meets or exceeds ISO 7/Class 10,000 for cGMP, IEST, ASTM and ISO 14644-1 standards. Select optional ULPA filter for ISO 6/Class 1,000.
- Vertical flow configuration fits a smaller footprint, encompassing less work space. It can also be easier to configure for tall equipment or processes requiring more vertical space.
- Operation status indicator (OSI) light glows continuously when filtration unit is plugged in and turned on to confirm unit is operational. The OSI blinks when the unit is plugged in but switched off.
- Cleanroom-grade HEPA filter blower provides positive pressure laminar airflow and sweeps away particulate contamination from the work surface.
- Recessed LED lighting and a hinged access shield allow for high visibility and easy sample introduction.
- Static-dissipative PVC access shield minimizes static cling of particles to improve cleanliness and has increased chemical resistance against cleaning agents.
- Low-noise WhisperFlow® FFU reduces background noise, registers under 50 dBA at 12" (305 mm) from filter face for easy communication and minimal disruption.
- Includes: Hood frame, fan filter unit, LED lighting.
- Optional Accessories:
- ErgoHeight automatic height adjusting table: perfect for workstations holding heavy or fragile equipment that require frequent height adjustment.
- ULPA filter removes 99.999% of particles measured at 0.12µm or larger.
- Filter replacement alarm prevents costly operational interruptions and avoids damage to fan blower caused by excessive backpressure from long overdue filter replacement or other abnormalities.
- UV germicidal lamp to inhibit microbial growth in and around hood.
- Ionizing bar for ESD-sensitive applications.
- NOTE: ValuLine hoods are pre-configured designs that cannot be customized. Please call your Terra sales specialist to discuss appropriate models for custom requirements.
- NOTE: Laminar flow hoods are not appropriate in the presence of biohazards. Only an approved containment system, such as a Class II, Type A2 biosafety cabinet, should be used in applications requiring Biosafety Level (BSL) 2 or 3 containment.
Specs
• Airflow Direction: Vertical
• Sash Material: Static-Dissipative PVC
• Filter Type: HEPA
• Light Fixture: LED
• Inside Width: 48"
• Inside Height: 28.5"
• Inside Depth: 24"
• Sash Opening: 9"
• Sash Height: 14"
• Static-Dissipative PVC
• Sash Design: Manual/Tilt-Up
• Height: 42"
• Work Area Dimensions: 46" W x 24" D x 28.5" H
• Max Opening: 23" H
• Hood Design: Benchtop
• Manufactured by: Terra Universal
• Airflow Design: Vertical
• Frame Material: Polypropylene
• Width: 49"
• Depth: 24.5"
• Electronic Air Speed Control: No
• Model: ValuLine Vertical Laminar Flow Station
• ISO Rated Air Cleanliness: ISO 5
• Unit of Measure: EA
• Marks & Listings: UL, ULC
• Electrical Specifications: 120 V, 6 A, 720 W, 1 Ph, 50/60 Hz
• Weight, Product: 150 lb
• Dimensions, Product: 49" W x 24.5" D x 42" H
• Weight, Shipping: 240 lb
• Dimensions, Shipping: 55" W x 31" D x 47" H
• Package Type: Palletized
