Product Details
- Available Certified ISO Grade Designs: ISO 6, ISO 7, ISO 8
- Extra-wide dry cabinets for moisture-sensitive chemical and pharmaceutical drums
- Extends shelf life of dry sterile pharmaceutical powders and other hygroscopic chemicals and materials
- Spacious design allows storage of standard drum sizes as well as long parts that won't fit in smaller compartments
- Ideal for bulk pharmaceutical powders, chemicals and agricultural supplies
- UL-Listed desiccator cabinet and RH control system are designed and built to the highest standards required by defense and semiconductor industries for long-term reliability and protection against damage, injuries, and electrical hazards.
- Cabinet Design:
- Reinforced 304 stainless steel cabinet is ESD safe and provides industrial-strength storage. Enhanced corrosion resistance for environments that require cleaning frequently.
- Fittings included for nitrogen gas purge.
- Digital hygrometer displays relative humidity and temperature inside cabinet.
- Automatic RB™ (Relief/Bleed) valves relieve excess pressure inside the cabinet without allowing outside air or contaminants inside.
- 3-inch nylon feet facilitates leveling, allows cleaning underneath the cabinet, and prevents damage to cleanroom flooring.
- Door Design:
- Access doors with 304 stainless steel reinforced frames extend desiccator cabinet's service life and provide a tight seal.
- Santoprene® "e"-shape non-outgassing rubber gasket firmly compresses to eliminate leaks. The one-piece resilient rubber gasket maintains its shape after compression and won't flatten, warp, crack, or degrade like ordinary foam gasket. Gasket is also mechanically attached to the door frame to avoid adhesive failure common with gasket tapes.
- Heavy-duty stainless steel LiftLatches™ and hinges permits door removal and replacement without extra tools.
- Durable and removable lift-off stainless steel hinges eliminate corrosion, flaking, and contamination that commonly occur with ordinary chrome-plated hinges.
- OPTIONAL ACCESSORIES/FEATURES:
- Smart® automatic gas-purge maintains below 10% RH with 78% less nitrogen than a manual flow meter to optimize yields.
- Standard flowmeter for control of inert gas inflow.
- Locking lift latches - specify one per chamber.
- Casters for mobility and space optimization.
- 304 stainless steel pallets for easier loading and unloading in and out of storage cabinets.
- Note: Cabinet may be configured to exhaust harmful particles.
Specs
• Chamber Material: Powder Coated Steel
• Chamber Width: 46"
• Chamber Depth: 24"
• Chamber Height: 37"
• Drum Capacity: 2
• Drum Size: 30 gallons
• Chamber Dimensions: 45.75" W x 23.75" D x 32.25" H
• Opening Dimensions: 20.25" W x 31" H
• Unit of Measure: EA
• Marks & Listings: CE, UL, ULC
• Weight, Product: 120 lb
• Dimensions, Product: 46" W x 24" D x 37" H
• Weight, Shipping: 273 lb
• Dimensions, Shipping: 54" W x 45" D x 32" H
• Package Type: Palletized
