Product Details

  • Available ISO Ratings: ISO 5, ISO 6, ISO 7, ISO 8
  • Pre-wired for integration with Terra’s automated, cabinet-level humidity control systems: Dual Purge and NitroWatch
  • Sloping top minimizes particle retention, simplifies cleaning, and reduces disturbances to laminar flow from ceiling mounting HEPA filter/blowers
  • Nitrogen-purged cabinet maintains low- humidity storage conditions to extend product shelf lives
  • Heavy-duty latches and hinges provide years of trouble-free operation
  • Included stainless steel stand with nylon leveling feet raises cabinet 4.5" (114 mm)
  • Built-in digital thermohygrometer displays internal temperature and RH to help monitor conditions
  • static-dissipative PVC viewing windows
  • Reinforcing base support raises cabinet by 1” for unobstructed door swing
  • Order removable shelves separately (4 maximum; 15" clearance between each)
  • Each reinforced shelf supports 300-lb load and requires non-removable supports (installed whether or not shelves are specified)
  • Comes with (2) Automatic RB Valves and a stand installed
  • 304 Stainless Steel Large Non-locking LiftLatches™ included
  • Upgrade to Large Non-locking 316 Stainless Steel LiftLatch™

Specs

Chamber Dimensions: 46" W x 17" D x 83" H

Window Material: SDPVC

Material: Stainless Steel

Opening Dimensions: 21.25" W x 81" H

Number of Chambers: 1

Model: Series 300

Design: Cabinet

Maximum Shelf Load: 300 lb

Chamber Width: 46"

Chamber Depth: 17"

Chamber Height: 83"

Humidity Control: Cabinet Level

Door Type: Viewing Window

Door Design: Leak Tight

Unit of Measure: EA

Marks & Listings: CE, UL, ULC

Weight, Product: 419 lb

Dimensions, Product: 48" W x 18" D x 87.5" H

Weight, Shipping: 637 lb

Dimensions, Shipping: 54" W x 24" D x 101" H

Package Type: Crate
