Product Details

  • Standard Pull-Side Regular Mount, Track Arm with Full Width Cover
  • Includes: Full Width cover, track arm, double mode switch and cable
  • For 28"-44"  door width
  • Finish: Aluminum
  • Power requirements: 115 VAC +/–10%, 50/60 Hz, 6.6 A max; Branch Circuit Protection: 15 A min
  • Onboard Power Supply for Access Control Devices: 1.5A @ 24 VDC
  • Maximum Door Sizes: 36"-44" wide
  • Max Door Weight: 220 lbs.  (100 kg)
  • Operator Weight: 26.5 lbs.  (12 kg)
  • Operating Temperatures: 5° F to 122° F (–15° C to 50° C)
  • Maximum Opening Angle Powered: 110°
  • Maximum Opening Angle Manual: 180 Maximum Opening Angle
  • Non-handed and On-board Cycle Counter
  • Compatible with Terra Doors and Smart Pass-Through Chambers
  • Fully ADA Compliant and opens doors at precisely controlled speeds for optimum safety
  • Programmable options accommodates challenging door installations
  • Low footprint; 65% smaller than other comparable products on the market
  • Features: Advanced Power Assist (Helping Force), Blow Open integration into smoke ventilation systems, Permanent Hold Open, Obstacle Detection, Push & Go, Onboard Power Supply, Motion and Presence Sensors, Closing Speed and Latching Force (in case of power failure), Positive Mechanical Stops, Vestibule Function Synchronizing Options, Synchronized Integration for Pair of Doors, Pull Side or Push Side Applications, Full Complement of Painted and Architectural Finishes, Self-Diagnosis Status Indicator
  • Many other custom configurations available (talk to a product expert for details)

Specs

Type: Swing Door Operator

Opening Width: 28" to 44"

Unit of Measure: EA

Marks & Listings: UL

Electrical Specifications: 120 V, 50/60 Hz

Weight, Product: 27 Lbs

Dimensions, Product: 36"W x 6"D x 3"H

Weight, Shipping: 57 Lbs

Dimensions, Shipping: 42"W x 8"D x 5"H

Package Type: Box

  • Short video of the automatic door Cleanroom Automatic Door
Short video of the automatic door
